Duration: 3 days
Location: Warrendale, PA
Credits: 2.4 CEUs
Target audience
Electricians, project managers, field service engineers or technicians whose job responsibilities will include review and editing of electrical drawings.
Learning objective
The goal of this two and a half-day workshop is to have the student become familiar with reading and understanding various drawing types and styles for electrical distribution systems and equipment.
Abstract
Using drawings from various distribution systems and equipment, attendees will learn standard symbols and drawing styles used to represent electrical distribution systems and equipment. Attendees will be able to reference the physical equipment to drawings that will assist in LOTO planning and implementation, startup and commissioning activities, and troubleshooting.
Course topics include:
Standards
IEEE
Symbols
Distribution equipment
Protective devices
Device numbers
Types
System drawings
Single line
Riser
Impedance
Equipment-specific
Layout
Three line
Wiring
Control schematics
Arriving at our Training Centers
Gaining Access:
Upon arriving at our training center, proceed to the entrance marked "Entrance 1 (EESSD)". The door to enter the building is locked. Our staff will greet you upon arrival and take you to the appropriate training area. You will be asked to sign in for all events so that we can track building occupants in case of an emergency situation.
What to Wear:
Due to the nature of our training facilities and other events taking place, we ask that you wear business casual (or appropriate PPE if your event requires PPE in lab exercises) while in the facilities. Please do NOT wear shorts, open-toed shoes, or loose clothing that can get caught on equipment in the lab spaces.
Safety:
Our labs are working labs, as well as training and testing spaces. Equipment may or may not be energized with control voltages as well as three phase power. We ask that you do not open or operate any equipment within the facility
